Fuel Flow Meter FQ-2200CR

The FQ-2200CR Fuel Consumption Measurement System allows measuring fuel mass flow rate continuously in the range of 0.2 kg/ h to 108 kg/ h with high precision. The FQ-2200CR can be applied to any engine and vehicle test stand used for R& D, quality management, and production; and is an important tool for the development of internal combustion engines. High precision over the measuring range Diesel and gasoline, alcohol-based fuels up to 100% Integration into test automation system Data communication with 10 Hz User-friendly touch panel Easy setting of fuel pressure and temperature Measuring Unit Using Coriolis meter, it realizes simultaneous monitoring of mass flow in a wide range of 0.2 kg/ h to 108 kg/ h with fuel density. Fuel Conditioning Unit Integrated pumps and temperature control systems ensure a constant temperature level for measuring and for the engine fuel circuit. An optional pressure control modules enable the operator to adjust fuel supply pressure and return pressure. An optional heating module makes fuel temperature control possible: 5º C to 40º C higher than utility cooling water. User-Friendly Functionality Easy fuel changing function is available with quick operation from the control touch panel. A venting module provides purging function for removing air bubbles in fuel and ensures accurate measurement results.
